Description
SYSTEM SPECIFICATION
| Parameters | Model 700VA/850VA/900VA/1000VA/(12VDC) | Model – 1700VA/2000VA (24VDC) | Model – 2500VA/2000VA (36VDC) | Model – 3500VA (48VDC) | Model – 5KVA/ (48VDC) | Model – 6KVA/ (72VDC) | Model -7.5 KVA (96VDC) | Model – 10 KVA (120VDC) |
| UPS MODE
Low Cut Low Cut Recovery High Cut High Cut Recovery Change Over Time |
175 + 10V
185 + 10V 265 + 10V 255 + 10V <10ms |
|||||||
| WUPS MODE
Low Cut Low Cut Recovery High Cut High Cut Recovery Change Over Time |
90 + 10V
110 + 10V 295 + 10V 285 + 10V <30ms |
|||||||
| Output Voltage Range | 220V + 10% | |||||||
| Output Waveform | Pure Sine Wave | |||||||
| Output Frequency | 50Hz + 1% | |||||||
| Overload | >110% | |||||||
| Charging Current
(100AH – 135AH) |
12A + 2AMP (Factory Setting) | |||||||
| Charging Current
(150AH – 200AH) |
15A + 2AMP (Factory Setting) | |||||||
| Charging Boost Voltage (LA/Floded) | 14.0V + 0.2V each battery | |||||||
| Charging Boost Voltage (SMF/Tubular) | 14.5V + 0.2V each battery | |||||||
| Float Charging Voltage | 13.7V + 0.2V each battery | |||||||
