Description
SPECIFICATION
| Rating | 875VA 1500VA | |
| Input | Regulated UPS Mode | |
| Under Voltage
Under Voltage Restoration Over Voltage Over Voltage Restoration |
180 + 5V
185 + 5V 260 + 5V 255 + 5V |
|
| Unregulated UPS Mode | ||
| Under Voltage
Under Voltage Restoration Over Voltage Over Voltage Restoration |
100 + 10V
115 + 10V 285 + 10V 270 + 10V |
|
| Output | Maximum Power
Voltage (UPS Mode) Voltage (Mains Mode) Frequency (UPS Mode) Frequency (Mains Mode) Overload Transfer Time (typical a.s) |
875VA 1500VA
SINEWAVE 230V Nominal Same as Input 50Hz. + 2% Same as Input (45-55 Hz.) >110% 10ms. |
| Battery | Type
Voltage Number Typical Recharge Time Protection |
120 Ah-150Ah Lead Acid Type
12V 1 2 10-12Hrs. LOW BATTERY REVERSE POLARITY |
| Physical | Net Weight (Kg.)
Gross Weight (Kg.) Dimensions (LxWxH)(mm) |
10.20 17.12
11.15 18.37 380x360x180 485x380x220 |
| LED Display | UPS ON
Low Battery Pre-Alarm Battery Low Mains On Sensor Charge Overload Short Circuit No Load Shut Down MCB Trip |
Red
UPS On & Low Battery Red Red Red Red (Along with Mains On LED) Red Steady OVERLOAD BLINKING Red Sensor Charge (Blinking) |
| Alarms | Low Battery Pre-Alarm
Low Battery Trip Overload Short Circuit No Load Shut Down |
UPS Beeping after every 10 seconds
UPS Beeping Continuously for 10 seconds UPS Beeping Continuously for 10 seconds UPS Beeping Continuously for 10 seconds UPS Beeping Continuously for 10 seconds |
| Environmental | Operating Temperature
Storage Temperature Humidity |
0-400C (32-1040F)
0-400C (32-1040F) 0-95% RH non-condensing |
Due to Continuous Product improvements, specifications are subject to change without notice.
EQUIPMENT DETAILS
| Sr. No.: | ||
| RATING (VA) | DATE OF INSPECTION | DEALER’S INVOICE NO. & DATE OF SALE |
| 875
|
||
|
1500
|
||
